ALUXX ALUMINUM TECHNOLOGY
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
MAESTRO SUSPENSION TECHNOLOGY
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
Sizes: one size
Colors: Black/Red
Frame: ALUXX SL-Grade Aluminum, 120mm Maestro suspension
Fork: RockShox Recon Silver RL, 15x110mm 120mm, with remote lockout
Shock: RockShox Deluxe Select+
Handlebar: Giant Connect, 690mm
Stem: forged alloy Ahead, 50mm
Seatpost: alloy, single-bolt, 30.9x350
Saddle: Giant
Pedals: N/A
Shifters: SRAM SX Eagle
Front Derailleur: N/A
Rear Derailleur: SRAM SX Eagle
Brakes: Shimano BL-M201, hydraulic disc
Brake Levers: Shimano
Cassette: SRAM SX Eagle, 11x50
Chain: SRAM SX Eagle
Crankset: SRAM SX DUB, 32t
Bottom Bracket: SRAM DUB, press fit
Rims: Giant AM 26, sleeve-joint, 30mm inner width
Hubs: Giant Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Spokes: stainless, 14g
Tires[F]: Maxxis Minion DHF 26x2.35, [R]Maxxis Ikon 26x2.35
Extras: Giant 1x chain guide
Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
Colors: Black/Red
Frame: ALUXX SL-Grade Aluminum, 120mm Maestro suspension
Fork: RockShox Recon Silver RL, 15x110mm 120mm, with remote lockout
Shock: RockShox Deluxe Select+
Handlebar: Giant Connect, 690mm
Stem: forged alloy Ahead, 50mm
Seatpost: alloy, single-bolt, 30.9x350
Saddle: Giant
Pedals: N/A
Shifters: SRAM SX Eagle
Front Derailleur: N/A
Rear Derailleur: SRAM SX Eagle
Brakes: Shimano BL-M201, hydraulic disc
Brake Levers: Shimano
Cassette: SRAM SX Eagle, 11x50
Chain: SRAM SX Eagle
Crankset: SRAM SX DUB, 32t
Bottom Bracket: SRAM DUB, press fit
Rims: Giant AM 26, sleeve-joint, 30mm inner width
Hubs: Giant Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Spokes: stainless, 14g
Tires[F]: Maxxis Minion DHF 26x2.35, [R]Maxxis Ikon 26x2.35
Extras: Giant 1x chain guide
Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
-
- One Size
-
4’9”
5’5”
| ONE SIZE | ||
|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 15 |
| B | SEAT TUBE ANGLE | 73.0° |
| C | TOP TUBE LENGTH (inch) | 21.3 |
| D | HEAD TUBE LENGTH (inch) | 3.7 |
| E | HEAD TUBE ANGLE | 68.0° |
| F | FORK RAKE (inch) | 1.6 |
| G | TRAIL (inch) | 3.6 |
| H | WHEELBASE (inch) | 42 |
| I | CHAIN STAY LENGTH (inch) | 17.1 |
| J | BOTTOM BRACKET DROP (inch) | 0.4 |
| K | STACK (inch) | 21.8 |
| L | REACH (inch) | 14.6 |
| M | STAND OVER HEIGHT (inch) | 25.9 |
| N | HANDLEBAR WIDTH (inch) | 27.2 |
| O | STEM LENGTH (inch) | 2 |
| P | CRANK LENGTH (inch) | 6.3 |
| Q | WHEEL SIZE | 26" |
